58
380 Series Strip Lamps
5 year
warranty
Surface mounting brackets available for
235 & 380 series strip lamps, see page 59
380 Series Strip Lamps
Dimensions: 383 x 25 x 16mm
Cut out: 348 x 19mm
Available in 12V or 24V
Fully Waterproof
Vertical or Horizontal Mounting
40cm Hardwired Cable
Mounting Brackets Available (p.59)
Part Numbers
380A12E
Indicator (12V)
380A24E
Indicator (24V)
380R12E
Stop / Tail (12V)
380R24E
Stop / Tail (24V)
380W12E
Illumination (12V)
380W24E
Illumination (24V)
Current Draw
(13.8V / 28V)
Ind:
0.18A / 0.10A
Stop:
0.16A / 0.12A
Tail:
0.04A / 0.01A
Ill:
0.14A / 0.09A
383mm
25mm
16mm
