060
LED Autolamps Europe LLP
Tel:
+44 (0)121 313 2222
Fax:
+44 (0)121 313 2272
front / rear marker
1004LE
Left
1004RE
Right
Current Draw (13.8V / 28V):
0.04A / 0.04A
front / rear / side marker
1005LE
Left
1005RE
Right
Current Draw (13.8V / 28V):
0.09A / 0.09A
Overall Size: 193 x 166 x 66mm
Cable Length: 200mm
193mm
66mm
166mm
1004 & 1005 series
heavy-duty stalk marker lamps
1004 & 1005 series –
stalk marker Lamps
•Rubber stalk lamps – front and rear position with optional side marker
•A high level of flexibility in the rubber neck makes the lamp highly
resilient to impact damage
•Shock, water & dust proof
•Highly efficient – low current draw
Voltage Range:
12/24V
Warranty:
5 years
Ingress Protection:
IP67
Approval:
ECE & EMC
5 year
warranty
12/24V
IP67
