LED Autolamps Work Lamps 2015 - page 20

18
LED Autolamps Europe LLP /www.ledautolamps-uk.com
11027BM
High-Powered Square Flood Lamp
9 x 3W LEDs
Dimensions (mm):
Voltage:
Beam Type:
Housing:
Lens:
Weight (kg):
Ingress Protection:
Raw Lumens:
Effective Lumens:
Current Draw (12/24V):
Colour Temperature:
Warranty:
128 x 110 x 55
12/24V Multivolt
Flood
Black Powder-Coated Die Cast Aluminium
Polycarbonate
0.83kg
IP67
2160lm
1065lm
1.8A/0.9A
6000K
2 Years
6.5lx
10m 25m 51m
1lx 0.25lx
11027BM
– High-Powered Square flood lamp
110mm 55mm
128mm
110mm 55mm
