034
LED Autolamps Europe LLP
Tel:
+44 (0)121 313 2222
Fax:
+44 (0)121 313 2272
5 year
warranty
12/24V
IP67
stop / tail / indicator /
reverse / fog
100bstiwfmle
Current Draw (13.8V / 28V):
Stop: 0.38A / 0.24A, Tail: 0.04A / 0.07A,
Indicator: 0.38A / 0.23A,
Reverse: 0.31A / 0.17A, Fog: 0.42A / 0.21A
stop / tail / indicator / fog
100bfarme
Current Draw (13.8V / 28V):
Stop: 0.38A / 0.24A, Tail: 0.04A / 0.07A,
Indicator: 0.38A / 0.23A, Fog: 0.42A / 0.21A
stop / tail / indicator
100barrme
Current Draw (13.8V / 28V):
Stop: 0.38A / 0.24A, Tail: 0.04A / 0.07A,
Indicator: 0.38A / 0.23A
stop / tail / indicator /
reverse / fog
100bstiwfmre
Current Draw (13.8V / 28V):
Stop: 0.38A / 0.24A, Tail: 0.04A / 0.07A,
Indicator: 0.38A / 0.23A,
Reverse: 0.31A / 0.17A, Fog: 0.42A / 0.21A
stop / tail / indicator / reverse
100brawme
Current Draw (13.8V / 28V):
Stop: 0.38A / 0.24A, Tail: 0.04A / 0.07A,
Indicator: 0.38A / 0.23A,
Reverse: 0.31A / 0.17A
Overall Size: 350 x 120 x 31mm
Cable Length: 400mm
100 series
triple combination rear lamps – black
100 series –
triple combination rear Lamps – Black
•100mm square lamp modules
•Black triple surface
mounting bracket
•Tough polycarbonate lenses
•Shock, water & dust proof
•Replacement lamp modules
available;
100AMEB, 100RMEB,
100WMEB, 100FMEB
Voltage Range:
12/24V
Warranty:
5 years
Ingress Protection:
IP67
Approval:
ECE & EMC
350mm
120mm
31mm
