030
LED Autolamps Europe LLP
Tel:
+44 (0)121 313 2222
Fax:
+44 (0)121 313 2272
Stop / Tail / Indicator / Fog
80BFARME
Current Draw (13.8V / 28V):
Stop: 0.33A / 0.25A, Tail: 0.06A / 0.04A, Indicator: 0.29A / 0.22A,
Fog: 0.42A / 0.21A
Stop / Tail / Indicator / Reverse
80BRAWME
Current Draw (13.8V / 28V):
Stop: 0.33A / 0.25A, Tail: 0.06A / 0.04A, Indicator: 0.29A / 0.22A,
Reverse: 0.17A / 0.21A
Stop / Tail / Indicator
80BARRME
Current Draw (13.8V / 28V):
Stop: 0.33A / 0.25A, Tail: 0.06A / 0.04A, Indicator: 0.29A / 0.22A
5 year
warranty
12/24V
IP67
Overall Size: 278 x 100 x 28mm
Cable Length: 400mm
80 series
triple combination rear lamps – Black
80 series –
triple combination rear Lamps – Black
•80mm square lamp modules
•Black triple surface mounting
bracket
•Tough polycarbonate lenses
•Shock, water & dust proof
•Replacement lamp modules
available;
80AMEB, 80RMEB,
80WMEB, 80FMEB
•For vertical mounting bracket
see p.034
Voltage Range:
12/24V
Warranty:
5 years
Ingress Protection:
IP67
Approval:
ECE & EMC
278mm
240mm
28mm
100mm
