Rear Lamps & Markers Catalogue - page 29

LED Autolamps Europe LLP Email: [email protected] Web: www.ledautolamps-uk.com
021
5 year
warranty 12/24V IP67
Indicator
135AME Surface Mount Bracket
135AMGE Recess Mount Grommet
Current Draw (13.8V / 28V):
Indicator: 0.16A / 0.06A
fog
135FME Surface Mount Bracket
135FMgE Recess Mount Grommet
Current Draw (13.8V / 28V):
Fog: 0.33A / 0.2A
replacement brackets
135B Bracket
135g Grommet
Triple Mounting Bracket*
135Bkt Chrome
*Fits 135 series grommet mounted lamps
Stop / Tail
135RME Surface Mount Bracket
135RMgE Recess Mount Grommet
Current Draw (13.8V / 28V):
Stop: 0.11A / 0.08A, Tail: 0.02A / 0.02A
Reverse
135WME Surface Mount Bracket
135WMgE Recess Mount Grommet
Current Draw (13.8V / 28V):
Reverse: 0.23A / 0.19A
Overall Size, Bracket: 135 x 38 x 24mm
Overall Size, Grommet: 145 x 48 x 20mm
Cable Length: 180mm
135 series
slimline rear lamps
slimline rear Lamps
– 135 series
•Slimline design
•Highly durable
•Available in surface or recess mount
•Shock, water & dust proof
•Signature diamond pattern lens
Voltage Range: 12/24V
Warranty: 5 years
Ingress Protection: IP67
Approval: ECE & EMC 
144mm 133mm
48mm
36mm
135mm
24mm
80mm
38mm
133mm
145mm
36mm
48mm
24mm
38mm
135mm 80mm
135B
135G
135BKT
