Rear Lamps & Markers Catalogue - page 19

LED Autolamps Europe LLP Email: [email protected] Web: www.ledautolamps-uk.com
011
Stop / Tail / Indicator
EU140STIM
Current Draw (13.8V / 28V):
Stop: 0.54A / 0.17A, Tail: 0.08A / 0.06A,
Indicator: 0.77A / 0.16A
Reverse / Tail /
Supplementary stop
EU140TRM
Current Draw (13.8V / 28V):
Reverse: 0.39A / 0.23A, Tail: 0.08A / 0.06A,
Stop: 0.54A / 0.17A
Fog / Tail /
Supplementary Stop
EU140TFM
Current Draw (13.8V / 28V):
Fog: 0.38A / 0.24A, Tail: 0.08A / 0.06A,
Stop: 0.54A / 0.17A
Overall Size: ø140 x 20mm
Cable Length: 400mm
Supplementary stop function to be used only in combination with approved stop lamp (EU140STIM)
See p. iv–v for more information
click & stick mounting system
only 20mm deep
diamond pattern lens
EU140 Series
low-profile round rear Lamps
low-profile round rear Lamps
– eu140 Series
•Modern ’hamburger’ style design
•Shock, water & dust proof
•Signature diamond pattern lens
•Low-profile – only 20mm depth
•Harness system compatible
(EU140STIM only)
Voltage Range: 12/24V
Warranty: 5 years
Ingress Protection: IP67
Approval: ECE & EMC 
140mm
80mm
20mm
LED AUTOLAMPS INNOVATION
