008
LED Autolamps Europe LLP
Tel:
+44 (0)121 313 2222
Fax:
+44 (0)121 313 2272
Overall Size: 250 x 80 x 24mm
Cable Length: 400mm
5 year
warranty
12/24V
IP67
250 Series
4-function Compact Combination Lamps
Stop / Tail / Indicator /
reverse / Reflector
250WARM
Current Draw (13.8V / 28V):
Stop: 0.04A / 0.17A , Tail: 0.32A / 0.03A,
Indicator: 0.32A / 0.17A,
Reverse: 0.24A / 0.13A
Stop / Tail / Indicator /
Fog / Reflector
250FARM
Current Draw (13.8V / 28V):
Stop: 0.04A / 0.17A , Tail: 0.32A / 0.03A,
Indicator: 0.32A / 0.17A, Fog: 0.15A / 0.08A
Stop / Tail / Indicator /
reverse / Reflector
250ARWM
Current Draw (13.8V / 28V):
Stop: 0.04A / 0.17A , Tail: 0.32A / 0.03A,
Indicator: 0.32A / 0.17A,
Reverse: 0.24A / 0.13A
250 Series –
4-function
Compact Combination Lamps
•Signature diamond pattern lens
•Shock, water & dust proof
•Integrated reflex reflectors
•Low-profile depth – only 24mm
Voltage Range:
12/24V
Warranty:
5 years
Ingress Protection:
IP67
Approval:
ECE & EMC
200mm
250mm
24mm
80mm
•2-pin accessory connection –
compatible with ‘plug & play’ number
plate lamps, see p.062–063
