LED Autolamps Europe LLP
Email:
Web:
007
Stop / Tail / indicator
235bsti12
12V, Black
235wsti12
12V, White
235bsti24
24V, Black
235wsti24
24V, White
Current Draw (13.8V / 28V):
Stop: 0.17A / 0.08A, Tail: 0.02A / 0.02A,
Indicator: 0.17A / 0.08A
Stop / Tail / indicator
380bsti12
12V, Black
380wsti12
12V, White
Current Draw (13.8V / 28V):
Stop: 0.2A / 0.1A, Tail: 0.04A / 0.02A,
Indicator: 0.2A / 0.1A
new
new
237mm
25mm
16mm
Overall Size: 237 x 25 x 16mm
Cut Out Size: 203 x 19mm
Cable Length: 400mm
Overall Size: 383 x 25 x 16mm
Cut Out Size: 348 x 19mm
Cable Length: 400mm
383mm
25mm
16mm
5 year
warranty
12V
or
24V
IP67
235 & 380 series
compact combination rear strip lamps
compact combination rear strip Lamps
– 235 & 380 series
•Super slimline design
•Highly durable
•Shock, water & dust proof
•Designed to be recess mounted,
or surface mounted with bracket
•Available with black or white PCB
•Range of surface mount brackets
available, see p.046
Voltage Range:
12V or 24V
Warranty:
5 years
Ingress Protection:
IP67
Approval:
ECE & EMC
