006
LED Autolamps Europe LLP
Tel:
+44 (0)121 313 2222
Fax:
+44 (0)121 313 2272
Overall Size: 135 x 38 x 24mm
Cable Length: 180mm
Overall Size: 145 x 48 x 20mm
Cut Out Size: 133 x 36mm
Cable Length: 180mm
5 year
warranty
12/24V
IP67
135 Series –
slimline
Compact Combination Lamps
stop / tail / Indicator
135ARME
Surface Mount Bracket
Current Draw (13.8V / 28V):
Stop: 0.07A / 0.08A, Tail: 0.02A / 0.02A, Indicator: 0.19A / 0.11A
stop / tail / Indicator
135ARMGE
Recess Mount Grommet
Current Draw (13.8V / 28V):
Stop: 0.07A / 0.08A, Tail: 0.02A / 0.02A, Indicator: 0.19A / 0.11A
replacement brackets
135B
Surface Mount Bracket
135G
Recess Mount Grommet
135 Series
slimline compact combination lamps
•Slimline design
•Highly durable
•Shock, water & dust proof
•Signature diamond pattern lens
•High-brightness LEDs
•Highly efficient – low current draw
•Available in surface or recess mount
Voltage Range:
12/24V
Warranty:
5 years
Ingress Protection:
IP67
Approval:
ECE & EMC
145mm
133mm
48mm
36mm
80mm
135mm
24mm
38mm
