Rear Lamps & Markers Catalogue - page 9

LED Autolamps Europe LLP Email: [email protected] Web: www.ledautolamps-uk.com
001
•2-pin accessory connection –
compatible with ‘plug & play’ number
plate lamps, see p.062–063
Stop / Tail / Indicator / Reflector
100BARE 12V
100BARE2 12V (Twin Pack)
100ARME 12/24V
100ARME10 12/24V (w/ 10m Cable)
Current Draw (13.8V / 28V):
Stop: 0.15A / 0.12A, Tail: 0.07A / 0.06A, Indicator: 0.11A / 0.07A
Stop / Tail / Indicator / Reflector
150BARE 12V
150BARE2 12V (Twin Pack)
150ARME 12/24V
150ARME10 12/24V (w/ 10m Cable)
Current Draw (13.8V / 28V):
Stop: 0.15A / 0.12A, Tail: 0.07A / 0.06A, Indicator: 0.11A / 0.07A
•Signature diamond pattern lens
•Shock, water & dust proof
•Fully submersible up to 1m
•Harness system compatible
Voltage Range: 12V or 12/24V
Warranty: Lifetime
Ingress Protection: IP67
Approval: ECE & EMC 
80mm
24mm
150mm
100mm
Overall Size: 100 x 100 x 22mm
Cable Length: 400mm
Overall Size: 150 x 80 x 24mm
Cable Length: 400mm
Compact Combination Lamps
– 100 & 150 Series
100 & 150 Series
Compact Combination Lamps
70mm
100mm
22mm
lifetime
warranty
12V or
12/24V IP67
